Evora LDE 0500 (1/2") double diaphragm air-operated pump
Skip image gallery
Compact & powerful
Resistant to chemicals
ATEX option available
*Illustration may differ from the actual product
Delivery time on request
Product number:
5222-100
Product information "Evora LDE 0500 (1/2") double diaphragm air-operated pump"
Versatile pump for aggressive and viscous media
This metal version with aluminium housing and TPE-PTFE sandwich diaphragms is designed for lubricants, alcohols and solvents. The optional ATEX version is also suitable for potentially explosive atmospheres.
Typical applications:
- Chemical processes with alcohols and solvents
- Oil and gas industry
- Applications with solvent mixtures in paints & varnishes
Advantage: Robust metal version for demanding media, with explosion protection option for Zone 1.
| Air connection (double-diaphragm pump): | 1/4" BSP |
|---|---|
| Air pressure (max. bar): | 8 |
| Ball/Seal: | PTFE |
| Certification: | ATEX Directive (ATEX Directive 2014/34/EU) |
| Connection (double-diaphragm pump): | 1/2" BSP female thread |
| Delivery head (up to max. m wc)*.: | 80 |
| Diaphragm (double diaphragm): | TPE + PTFE |
| Displacement volume (in cm³): | 75 |
| Explosion protection: | Yes |
| Flow rate (up to max. l/min)*.: | 76 |
| Housing/ball seat: | Aluminium |
| Liquid temperature (max °C): | 100 |
| Matchcode (DMP): | LDE-0500-EX-ALX-YTATGRR-00 |
| Max. Solid size (mm): | 3,2 - 3,8 |
| Max. Suction height: | 9 mWS wet (4 mWS dry) |
| Operating point (l/min): | 45 |
| Viscosity (up to max. mPas)*.: | 7500 |
Skip product gallery
Similar Products
Compact & powerful
Resistant to chemicals
ATEX option available
Evora LDE 050M (1/2") double diaphragm air-operated pump
