Practical examples for mixing
Suitable products for mixing
Skip product gallery
Stainless steel shaft
Impeller
Pump tube PP for mixing and pumping
for low-viscosity alkaline solutions
Description:
The drum pump is suitable for corrosive, aqueous to slightly viscous media. Depending on the application, various motors are available which can be combined with the pumping unit at any time. This gives you flexibility at all times and saves important resources.
Also available in special immersion depths from 200 - 2500 mm
Pumping unit equipped with Lutz original handwheel
Suitable for mixing and pumping oils such as rapeseed oil and vegetable oil
Features & advantages
Optionally with electric or compressed air drive
No lubricants and therefore no contamination of the pumped medium by lubricants
Two functions (pumping and mixing) in one device
No leaks if the pumping unit is tilted or moved
High mixing and conveying capacity for thorough homogenisation
switching between the pumping and mixing functions takes place without interrupting ongoing operation, which is made possible by a small lever on the handwheel
HC Wave
Impeller
Pump tube PP for mixing and pumping
for low-viscosity acids
Description:
The Lutz pumping station (PP) is suitable for corrosive, aqueous to slightly viscous media. Depending on the application, various motors are available which can be combined with the pumping station at any time. This gives you flexibility at all times and saves important resources.
Also available in special immersion depths from 200 - 2500 mm
Pumping unit equipped with Lutz original handwheel
Suitable for mixing and pumping oils such as rapeseed oil and vegetable oil
Features & advantages
Optionally with electric or compressed air drive
No lubricants and therefore no contamination of the pumped medium by lubricants
Two functions (pumping and mixing) in one device
No leaks if the pumping unit is tilted or moved
High mixing and conveying capacity for thorough homogenisation
switching between the pumping and mixing functions takes place without interrupting ongoing operation, which is made possible by a small lever on the handwheel
Diaphragm pumps mixing system
Mixing and pumping (explosion-proof)
Description:
The new diaphragm pump mixing system with an integrated compressed air-driven double diaphragm pump is the perfect solution for liquids that need to be mixed before processing and then pumped or that also contain small solids. The mixing and pumping process takes place via a suction and mixing pipe and a 3-way valve. The pre-assembled system is ready for immediate use in just a few simple steps and is also suitable for potentially explosive liquids.
Mixing and pumping integrated in one system
Examples of media: Paints and varnishes, emulsions, dispersions, suspensions, water/oil mixtures, liquids with increased viscosity and solids content
Properties & advantages
Quick installation and time saving due to easy handling
Compact design
Base plate offers good stability on the container lid
Easy to insert into the 2" bunghole of the container using a balancer or overhead crane
No additional mixer required
HC Wave
ROTOR
Pump tube PP for mixing and pumping
for low-viscosity acids
Description:
The Lutz pumping station (PP) is suitable for corrosive, aqueous to slightly viscous media. Depending on the application, various motors are available which can be combined with the pumping station at any time. This gives you flexibility at all times and saves important resources.
Also available in special immersion depths from 200 - 2500 mm
Pumping unit equipped with Lutz original handwheel
Suitable for mixing and pumping oils such as rapeseed oil and vegetable oil
Features & advantages
Optionally with electric or compressed air drive
No lubricants and therefore no contamination of the pumped medium by lubricants
Two functions (pumping and mixing) in one device
No leaks if the pumping unit is tilted or moved
High mixing and conveying capacity for thorough homogenisation
switching between the pumping and mixing functions takes place without interrupting ongoing operation, which is made possible by a small lever on the handwheel
Foodstuffs
Explosion protection
ROTOR
Pump tube Niro for mixing and pumping - PURE
for Foodstuffs (PURE series)
Description:
The Lutz pumping unit for mixing and pumping (stainless steel) PURE is suitable for aqueous and fatty foods. Depending on the application, various motors are available which can be combined with the pumping unit at any time. This gives you flexibility at all times and saves important resources.
Also available in special immersion depths from 200 - 2500 mm
Pumping unit equipped with Lutz Original handwheel
for mixing and pumping alcoholic foodstuffs, cosmetics and pharmaceutical products as well as flammable cleaning agents
Properties & advantages
Physiologically safe design
Food-safe connections
High mixing and conveying capacity for thorough homogenisation
two functions (pumping and mixing) in one device
Approved according to FDA and Regulation (EC) 1935/2004
Approved in accordance with ATEX Directive 2014/34/EU, category 1/2
Stainless steel shaft
ROTOR
Pump tube PP for mixing and pumping
for low-viscosity alkaline solutions
Description:
The Lutz pumping station (PP) is suitable for corrosive, aqueous to slightly viscous media. Depending on the application, various motors are available which can be combined with the pumping station at any time. This gives you flexibility at all times and saves important resources.
Also available in special immersion depths from 200 - 2500 mm
Pumping unit equipped with Lutz original handwheel
Suitable for mixing and pumping oils such as rapeseed oil and vegetable oil
Features & advantages
Optionally with electric or compressed air drive
No lubricants and therefore no contamination of the pumped medium by lubricants
Two functions (pumping and mixing) in one device
No leaks if the pumping unit is tilted or moved
High mixing and conveying capacity for thorough homogenisation
switching between the pumping and mixing functions takes place without interrupting ongoing operation, which is made possible by a small lever on the handwheel
Explosion protection
ROTOR
Pump tube Niro for mixing and pumping
for flammable liquids
Description:
The Lutz pumping station (stainless steel) is suitable for corrosive, aqueous to slightly viscous media. Depending on the application, various motors are available which can be combined with the pumping station at any time. This gives you flexibility at all times and saves important resources.
Also available in special immersion depths from 200 - 2500 mm
Pumping unit equipped with Lutz original handwheel
Suitable for mixing and pumping alternative fuels, oils and flammable liquids
Features & benefits
Also available with Tri-Clamp connection
Optionally with electric or compressed air drive
two functions (pumping and mixing) in one device
No leaks when the pump unit is tilted or moved
High mixing and conveying capacity for thorough homogenisation
switching between the pumping and mixing functions takes place without interrupting ongoing operation, which is made possible by a small lever on the handwheel
