Evora LDE 1500 (1 1/2") air-operated diaphragm pump
Skip image gallery
High delivery capacity
Resistant to chemicals
ATEX option available
*Illustration may differ from the actual product
Delivery time on request
Product number:
5242-200
Product information "Evora LDE 1500 (1 1/2") air-operated diaphragm pump"
Versatile metal pump for solvents and process fluids
The LDE 1500 AL-TPE/PTFE combines a robust aluminium housing with PTFE-Keyflex diaphragms for high chemical resistance and process reliability. It is ideal for pumping solvents, alcohols, lubricants and neutral process media.
With optional ATEX approval, this double diaphragm pump can also be used in potentially explosive zones. Its maintenance-friendly design and self-priming construction ensure high system availability and reliable pumping performance.
Brief advantages:
- Robust metal design with PTFE diaphragms
- Suitable for solvents and neutral liquids
- Optionally ATEX-certified for hazardous areas
| Air connection (double-diaphragm pump): | 1/2" BSP |
|---|---|
| Air pressure (max. bar): | 8 |
| Ball/Seal: | PTFE |
| Betriebspunkt (l/min): | 200 |
| Certification: | ATEX Directive (ATEX Directive 2014/34/EU) |
| Connection (double-diaphragm pump): | 1 1/2" BSP female thread (DN 40) |
| Delivery head (up to max. m wc)*.: | 80 |
| Diaphragm (double-diaphragm pump): | TPE + PTFE |
| Explosion protection: | Yes |
| Flow rate (up to max. g/min)*.: | 97.74 |
| Gehäuse/Kugelsitz: | Alu |
| Liquid temperature (max. °C): | 90 (194,0 °F) |
| Matchcode (DMP): | LDE-1500-00-PPA-LTPTGRR-00 |
| Max. Feststoffgröße (mm): | 7 |
| Max. Saughöhe: | 9 mWS nass (4,5 mWS trocken) |
| Verdrängungsvolumen (in cm³): | 670 |
| Viscosity (up to max. mPas)*.: | 30000 |
