Diaphragm pump accessories
Thread M6
Vibration damper set
Cushioning during foot mounting
Description:
The vibration damper set ensures the damping of vibrations, shocks and impacts. The set consists of 4 vibration dampers including fastening material.
Thread M6 / M8 / M 12
Features & advantages
M6 / M8 / M 12 thread standard in accordance with DIN 13-1
Thread M6
Vibration damper set
Attenuation on release
Description:
The vibration damper set ensures the damping of vibrations, shocks and impacts. The set consists of 4 vibration dampers including fastening material.
M6 / M8 thread
Features & advantages
M6 / M8 thread standard in accordance with DIN 13-1
Food
Ex-Schutz
DN 25 (1")
Universal chemical hose
for chemicals, food and hygiene products
Description:
The hose is suitable for pure chemicals, cosmetics, photographic chemicals, paints and adhesives, detergents and cleaning agents, hygiene products, as well as food and luxury foods. It is FDA and USP Class VI compliant and is electrically conductive so that it can also be used in potentially explosive environments.
Also available in special lengths on request
Nominal width: DN 13 / DN 19 / DN 25 / DN 32 / DN 38 / DN 50
Features & advantages
Operating pressure up to max. 16 bar
Colour coding: "blue/white/blue".
Complies with EU regulations 10/2011 and 1935/2004
Underpressure max 0.9 bar
PP
DN 40 x 1 1/2" AG
Threaded flange
for the double diaphragm pump 1 1/2"
Description:
The threaded flange is used to connect individual components to the double diaphragm pump. The flange includes the necessary screws and seals.
Special connections are available on request
Properties & advantages
Materials: PP / PVDF / aluminium / stainless steel (1.4571)
Connections: DN 40 to 1 1/2" AG / DN 38 to 1 1/2" AG
PP
DN 50 x 2" AG
Threaded flange
for the double diaphragm pump 2"
Description:
The threaded flange is used to connect individual components to the double diaphragm pump. The flange includes the necessary screws and seals.
Special connections are available on request
Properties & advantages
Materials: PP / PVDF / aluminium / stainless steel (1.4571)
Connection: DN 50 to 2" AG
Stainless steel (1.4571)
Suction strainer
for the suction hose
Description:
The suction strainer is attached to the appropriate suction hose. It prevents coarse impurities in the pump flow.
Material: Stainless steel (1.4571) and PA
Features & advantages
Connection: 1 1/4" AG
Prevention of contamination
1000 mm
1" AG
Suction pipe
made of stainless steel (Niro)
Description:
The suction pipe is required to be able to convey or suck in highly chemical media without the outer layer being attacked as when immersing a hose.
Material: Stainless steel (1.4571)
Features & advantages
Outer tube diameter 41 mm
Pipe length from 1000 - 1200 mm
Connections: 1 " AG and 1 1/4" AG
1000 mm
1 1/4" AG
Suction pipe
made of polypropylene (PP)
Description:
The suction tube is required to be able to convey or suck in highly chemical media without the outer layer being attacked as when immersing a hose.
Material: PP
Features & advantages
Outer tube diameter 41 mm
Tube length from 1000 - 1200 mm
Connection: 1 1/4" AG
Explosion protection
DN 25 (1")
max. 16 bar
Special chemical hose PTFE
for common and high-purity media
Description:
The hose is suitable for all common media, but also for high-purity products. It can be used either as a pressure or suction hose and complies with FDA and USP Class VI requirements. The hose is electrically conductive so that it can also be used in potentially explosive environments.
Also available in special lengths on request
Nominal diameter: DN 19 / DN 25
Properties & advantages
Operating pressure up to max. 16 bar
Colour coding: "blue/white/red"
Fulfils EU regulations 10/2011 and 1935/2004
Food
Explosion protection
DN 25 (1")
Special chemical hose FEP
for high-purity products
Description:
The hose is suitable for all common media, but also for high-purity products. It can be used either as a pressure or suction hose and complies with FDA and USP Class VI requirements.
Also available in special lengths on request
Nominal width: DN 19 / DN 25 / DN 32 / DN 38 / DN 50
Features & advantages
Operating pressure up to max. 16 bar
Colour coding: "blue/white/red"
Vacuum max. 0.9 bar
Explosion protection
DN 19 (3/4")
2 m
Solvent hose set (NBR)
for highly flammable hydrocarbons
Description:
The hose set is suitable for a wide range of commercially available solvents. The hose is electrically conductive so that it can also be used in potentially explosive environments. The set is used to connect to the pumping station or dispensing nozzle.
Also available in special lengths on request
Electrically conductive
Features & advantages
Hose connection: 1 1/4" female thread
Nominal diameter: DN 19 (3/4")
Pre-assembled hose connections
Complies with EU regulations 10/2011 and 1935/2004
Explosion protection
DN 25 (1")
max. 16 bar
Solvent hose
for highly flammable hydrocarbons
Description:
The hose is suitable for a wide range of commercially available solvents. The hose is electrically conductive so that it can also be used in potentially explosive environments.
Also available in special lengths on request
Nominal width: DN 13 / DN 19 / DN 25 / DN 32 / DN 38 / DN 50
Electrically conductive
Features & advantages
Operating pressure up to max. 16 bar
Colour coding: blue
fulfils EU regulations 10/2011 and 1935/2004
Underpressure max 0.9 bar
PP
DN 12 x 1/2" AG
Screw-in hose nozzle
for the double diaphragm pump 1/2"
Description:
The screw-in hose nozzle enables the direct connection of hoses to the pressure or suction nozzle of the double diaphragm pump.
Material PP
Features & advantages
Connection type: DN 12 x 1/2" AG / DN 20 x 1/2" AG
PVDF
DN 8 x 1/4" AG
Screw-in hose nozzle
for the double diaphragm pump 1/4"
Description:
The screw-in hose nozzle enables the direct connection of hoses to the pressure or suction nozzle of the double diaphragm pump.
Materials PVDF / brass / stainless steel
Features & advantages
Connection type: DN 8 x 1/4" AG / DN 9 x 1/4" AG
PP
DN 25 x 1" AG
Screw-in hose nozzle
for the double diaphragm pump 1"
Description:
The screw-in hose nozzle enables the direct connection of hoses to the pressure or suction nozzle of the double diaphragm pump.
Materials PP / stainless steel
Features & advantages
Connection type: DN 25 x 1" AG
PP
DN 8 x 1/4" AG
Screw-in hose nozzle
for the double diaphragm pump 1/4"
Description:
The screw-in hose nozzle enables the direct connection of hoses to the pressure or suction nozzle of the double diaphragm pump.
Material PP
Features & advantages
Connection type: DN 8 x 1/4" AG / DN 12 x 1/4" AG
PP
DN 8 x 1/4" AG
Screw-in fitting
for the double diaphragm pumps 1/4"
Description:
The screw-in fitting enables the direct connection of hoses to the pressure or suction connection of the double diaphragm pump.
Materials PP / PVDF
Features & advantages
Connection type: DN 8 x 1/4" AG / DN 8 x 3/8" AG
PP
1/2" AG x 1 1/4" AG
Reducing nipple (on the product side)
for the double diaphragm pump 1/2"
Description:
The reducing nipple enables the connection of two different threaded sockets.
Special connections are available on request
Properties & advantages
Materials: PP / PVC / PVDF / stainless steel (1.4571) / brass
Connection 1/2" AG to 1 1/4" AG
Connection 1/2" AG to 1" AG
Connection 1/2" AG to 3/4" AG
PP
1" AG x 1 1/4" AG
Reducing nipple (on the product side)
for the double diaphragm pump 1" and the barrel pump connection 1" AG x 1 1/4" IG
Description:
The reducing nipple enables the connection of two different threaded sockets.
Special connections are available on request
Properties & advantages
Materials: PP / PVC / PVDF / stainless steel (1.4571) / brass
Connection 1" AG to 1 1/4" AG
DN 25 (1")
1 m
PVC spiral hose
fabric-reinforced
Description:
The hose is suitable for aggressive, non-flammable liquids. The hose is made of PVC with a fabric insert and an embedded galvanised steel wire helix. Perfect for conveying food liquids.
Also available in special lengths on request
Nominal width: DN 19 / DN 25 / DN 32 / DN 38 / DN 50
Features & advantages
Operating temperature max. 14 bar
Complies with EU regulations 10/2011 and 1935/2004
DN 9 (3/8")
max. 14 bar
1 m
PVC hose / compressed air hose
with fabric insert
Description:
The compressed air hose is used to supply air to the air motors or diaphragm pumps, but can also be used as a vapour recovery hose (DN 9) for the vapour recovery system for mobile operation.
Also available in special lengths on request
Nominal widths: DN 9 / DN 13
Properties & advantages
PVC hose with fabric insert
Operating pressure (nominal width DN 9) max. 14 bar
Operating pressure (nominal width DN 13) max. 10 bar
Explosion protection
Pulse set electronic
for the double diaphragm pump 1/4" to 3"
Description:
The pulse set records the strokes of the double diaphragm pump and is connected directly to the pump. The set consists of a pulse adapter with a 0.6 m long 2-pin connection cable and 7-pin coupling socket.
PP
PTFE
Pulsation damper PD III D
for the double diaphragm pumps 1/4"
Description:
The pulsation dampers are containers filled with a gas cushion. A diaphragm separates the gas cushion from the system fluid. Pulsation dampers store and discharge part of the stroke volume in the stroke rhythm of the double diaphragm pump, whereby the gas cushion is compressed or decompressed accordingly. This makes the pulsating flow rate of the pump almost uniform.
Adjustable air control
Materials: PP / PVDF / stainless steel
Features & advantages
Connection type on the medium side: 1/2" IG
Connection type on air side: 1/4" AG
Max. operating pressure 10 bar
ensure an almost uniform volume flow, which increases the accuracy of flow meters
Compensation of pressure surges (water hammer) protects installed fittings
Prevents pipe vibrations that cause material fatigue and pipe breakages
PP
PTFE
Pulsation damper PD I D
for the double diaphragm pumps 1 1/2" to 2"
Description:
The pulsation dampers are containers filled with a gas cushion. A diaphragm separates the gas cushion from the system fluid. Pulsation dampers store and discharge part of the stroke volume in the stroke rhythm of the double diaphragm pump, whereby the gas cushion is compressed or decompressed accordingly. This makes the pulsating flow rate of the pump almost uniform.
Adjustable air control
Materials: PP / PVDF / stainless steel
Features & advantages
Connection type on the medium side: 2" IG
Connection type on air side: 1/4" AG
Max. operating pressure 10 bar
ensure almost uniform volume flow, which increases the accuracy of flow meters
Compensation of pressure surges (water hammer) protects installed fittings
Prevents pipe vibrations that cause material fatigue and pipe breakages
