Peristaltic pump: PERIDOS FXM 2
*Abbildung kann vom tatsächlichen Produkt abweichen
Product information "Peristaltic pump: PERIDOS FXM 2"
PERIDOS FXM 2 - The low-maintenance Peristaltic pump: for abrasive and outgassing media
High performance. Low maintenance. Industry 4.0-ready.
The PERIDOS FXM 2 from Lutz-Jesco is the high-performance peristaltic pump for abrasive, viscous or corrosive media - designed for maximum process reliability, ultra-fine dosing and uninterrupted 24/7 operation.
For demanding dosing processes in harsh industrial environments
Whether in water and wastewater treatment, the chemical industry or mining: the FXM 2 impresses with its precise delivery, intuitive control and maintenance-optimised design. Ideal for anyone who expects robust technology without compromises.
Precise dosing with maximum control
The FXM 2 doses up to 176 l/h at a delivery pressure of 8.6 bar - with an exceptional turndown ratio of 5000:1. This means that even fine adjustment down to 0.035 l/h is possible - ideal for sensitive processes with high reproducibility.
Real-time monitoring & leakage protection
Thanks to the optional Flow Verification Sensor (FVS) and non-contact leak detection (TLD), the FXM 2 recognises deviations immediately - and actively protects your processes from downtime, loss of quality or environmental damage.
Maintenance in minutes - without special tools
The hose is the only wearing part. It can be replaced in a few simple steps and without tools - completely without dismantling. This saves you time, reduces your operating costs and increases the availability of your system.
Intelligent networking - ready for Industry 4.0
Digital interfaces such as Ethernet/IP, Modbus TCP, 4-20 mA or 0-10 VDC enable seamless integration into existing SCADA and control systems. Up to 17 operating states can be recorded, analysed and actively controlled.
✅ Advantages of the Peristaltic pump: FXM 2:
- Self-priming & dry-running safe: Maximum reliability in 24/7 operation
- High delivery capacity: up to 176 l/h at 8.6 bar - ideal for abrasive and corrosive media: ...
- Industry-4.0-capable: Ethernet/IP, Modbus TCP, 0-10 VDC, 4-20 mA
Low maintenance & efficient: tool-free hose change in just a few minutes
- Robust construction: Powder-coated aluminium, chemical-resistant hoses
- SCADA-compatible : Up to 17 operating parameters can be analysed
- Digitally networkable: SCADA/DCS integration via Modbus TCP, Ethernet/IP, 0-10 VDC, 4-20 mA
- Predictive maintenance: Optional pump monitor & leakage sensor for predictive maintenance
- Certified & safe: UL 778, CSA, WQA (NSF/ANSI/CAN 61 & 372)
| MATCHCODE: | 0110R0028P021A21B |
|---|
